Laser Sensors Monitor Rails and Trains


Laser Distance Sensors Are Often Used in Railroad Inspections

With thousands of kilometers of track to maintain for train and railroad inspections, the rail industry needs high-speed measurement sensors to keep the trains reliably moving. Laser rangefinders are commonly used to monitor the position of trains, vehicles and cabs along different railroads and ore docks.

One customer is using an AR3000 to monitor the position of an iron-ore conveyor car as it traverses back and forth on top of the dock structure. The customer has installed (2) AR3000 sensors at a fixed mid-point aiming at a target towards each end.

The conveyor is roughly 800 feet in length so the customer chose the AR3000 distance measurement sensor for this application. Two AR3000 units are pointed at reflectors on opposite ends of their travel, for half-distance redundancy. The AR3000 Class-1 infrared (non-visible) measuring laser is considered safe for eye-exposure, without any restrictions. The Class-2 aiming (visible-red) laser is considered safe for unintentional eye exposure, but it can also be switched-off after the laser aim is set up.

The AR3000 is IP-67 rated, meaning it is sealed for outdoor weather exposure – and actually submersible to 1M.  The laser also has its own integrated heater, allowing operation from temperatures of -40F to 140F – without an enclosure.

These train and railroad inspections ensure precise position monitoring of vehicle positions to ensure operator safety. Similar vehicle positioning/detecting applications are solved using the Acuity long distance sensors.
